| Cadre: | Arcadex PRO Disc Brake Specification: Flat Mount 140/160 Bottom Braket Standard: PressFit 86.5 X Ø41 Rear Axle: thru12 OLD (Over-Locknut-Dimension): 142 mm Front Derailleur: Non Compatible Rear Derailleur: SRAM UDH Hanger type Max Chainring Compatibility: 38T-44T Minimun Chainline: 45.5 mm Tire Clearance: ETRTO 622-50 mm SeatPost O.D: Ø27.2 mm Material: Epoxy - SM Carbon Fiber Composite |
| Casque: | Bianchi Custom Acros ICR (Internal Cable Rounting) Spacers: 5 mm x1, 10 mm x3 Headtube Cover: Bianchi Costum Compresion Ring: 1.125 Inch Top Bearing: Angular contact Bearing 42x52x7 + seal Bottom Bearing: Angular contact Bearing 40x52x7 + seal Base Plate with seal, Steerer 1.5" (39.78 mm) |
| Gabel: | Suspension Fork: RockShox Rudy XPLR Travel: 30 mm Disc Brake Specification: Direct Flat Mount 160/180 Front Axle: thru12 OLD (Over-Locknut-Dimension): 100 mm Tire Clearance: ETRTO 622-50 mm Steer tube Diameter: Tapered 1 1/8" to 1.5" Fork Rake: 51 mm |
| Shifter: | Sram Apex AXS HRD Shift System |
| Derailleur arriere: | Sram GX Eagle Transmission (T-type AXS) |
| Crankset: | Sram Rival 1 WIDE 40T Crank Length: 170 mm-XS(47)-SM(51), 172.5 mmMD(55)-LG(58), 175 mm-XL(61) |
| Tretlager: | Sram DUB PressFit Road Wide 86.5 X Ø41 |
| Chaîne: | Sram GX Eagle Transmission Flattop |
| Cassette/Freewheel: | Sram GX Eagle Transmission, XS 1272 T-Type, 10-52T Driver Body Interface: XD |
| Bremse: | Sram APEX | Pad Type: Steel-Backed Organic |
| Disc Rotor: | Sram CenterLine Rotor Hub Interface: Centerlock Rotor Diameter: 160 mm (front&Rear) |
| Rim/Wheelset: | Velomann Terbium clincher and tubeless ready Rim Diameter: 700C Material: Carbon Rim Height: 30 mm Inner Wigth Channel: 25 mm |
| Pneus: | Pirelli Cinturato™ GRAVEL M Classic, 45-622 tan sidewall |
| Stem: | Velomann AICR Alloy Rise: -2° Steerer Diameter: 1-1/8" (28.6 mm) HB interface Diameter: 1-1/4" (31.8 mm) Stem Lengths: 80 mm - XS(47), 90 mm - SM(51), 100 mm-MD(55), 110 mm-LG(58),120 m -XL(61) |
| Liens: | Velomann Gravel ICR Alloy Flare: 16° | Drop: 130 mm | Reach 70 mm Interface Diameter: 1 1/4" (31.8 mm) HandleBar Widths: 400 - SX(47) SM(51), 420 - MD(55) LG(58), 440 -XL(61) |
| Grip/Tape: | Bianchi Hexagon tape 2.5 mm thickness, Full black |
| Tige de selle: | Velomann Carbon UD SeatPost O.D: Ø27.2 mm | Seatpost lengths: 300 mmSX(47), 350 mm-SM(51) MD(55), 400mm-LG(58) XL(61)" |
| Selle: | Velomann MITORA 149 H1 cover: soft touch | padding: foam | shell: nylon carbon rails: Aisi Steel | lenght: 250 mm | width: 149 mm weight: 230g ± 2" |
